Tube Rack 100 – SBS Rack, 100 mm

Tube Rack 100 is the SBS-format base of the 3D-LabEq platform for 15 mL and 50 mL centrifuge tubes and most other tube formats (not HPLC vials). It stands in a standard deck slot of your Opentrons OT-2 and takes the matching Tube Holders. It is the only rack that you can combine with Bottom Plates.

Highlights

Takes all matching 3D-LabEq Tube Holders – one rack for many tube formats
Fill with ice beneath the Tube Holder for passive cooling during the run
SBS footprint for a standard deck slot
Combinable with Bottom Plates for the correct height of 15 mL and 50 mL tubes

Use on other liquid handlers

Developed for the Opentrons OT-2. On other liquid handlers with an SBS-format deck, you can set up the product as custom labware; this use has not been validated by 3D-LabEq.

Data sheets are available on request – contact us. Custom sizes and other tube formats are also available on request.

Safety note: The supplied JSON labware file does not replace calibration. Before first use, you must calibrate the labware on your Opentrons robot yourself (Labware Position Check). Operation without calibration is at your own risk.

Which Tube Holder fits which Tube Rack?

The number in the rack name is the rack height in mm. All racks share the SBS footprint 127.8 × 85.8 mm.

Tube Holder	Tube Rack 20	Tube Rack 40	Tube Rack 70	Tube Rack 100
Tube Holder 24× 1.5 mL HPLC	✓²	–	on request	–¹
Tube Holder 24× 4 mL HPLC	–	✓	–	–¹
Tube Holder 24× 7 mL HPLC	on request	on request	on request	–¹
Tube Holder 96× PCR	✓	✓	✓	✓
Tube Holder 40× 1.5/2 mL	on request	✓	✓	✓
Tube Holder 48× PCR + 20× 1.5/2 mL	on request	✓	✓	✓
Tube Holder 12× 1.5/2 mL + 48× PCR	on request	✓	✓	✓
Tube Holder 15× 5 mL	on request	on request	on request	on request
Tube Holder 20× 5 mL	on request	on request	on request	on request
Tube Holder 24× 1.5/2 mL Flip Cap	on request	on request	on request	✓ with Bottom Plate 15
Tube Holders for 50 mL and 15 mL tubes	–	–	–	✓ with Bottom Plate

¹ HPLC vials slip through in Tube Rack 100.
² Better fit: Tube Rack 30 (coming soon).
✓ fits · – does not fit · on request: not yet confirmed – contact us.

Suitable vials

Tube Holder 24× 1.5 mL HPLC: Fits 1.5 mL ND9 HPLC vials, Ø 11.6 × 32 mm, and 2 mL screw-thread vials, Ø 11.5 × 32 mm.
Tube Holder 24× 4 mL HPLC: Fits 4 mL screw-thread vials, Ø 14.7 × 45 mm.

Dimensions of tubes vary by manufacturer; please check the fit before use.

Dimensions: base 127.8 × 85.8 mm (SBS format), top 132 × 90 × 100 mm (L × W × H)
Material: PETG, rust- and corrosion-free
Colours: white, black, blue, red
Disinfection: ethanol, isopropanol and hydrogen peroxide (up to 3 %, at room temperature); not autoclavable
Chemical resistance: see Knowledge Base
Ice-fillable – tested watertight for at least 72 hours
